Overview
The Kinocranes CPD20 Electric Forklift is a versatile 2.0-ton machine designed for high-efficiency logistics. It balances power and agility, making it the “go-to” choice for general warehousing, manufacturing plants, and distribution centers. With a stronger chassis and higher battery capacity options compared to lighter models, the CPD20 ensures consistent power delivery for heavier loads. The vehicle features a hydraulic mechanical braking system and a low center of gravity, providing exceptional stability when lifting loads to heights of 3 meters or more. Whether utilizing lead-acid or advanced lithium battery technology, the CPD20 delivers reliable, zero-emission performance.
Features
The 5.0 KW drive motor and 5.0 KW lifting motor provide ample power for fast lifting and travel.
Integrated seat belts and a rigid overhead guard protect the operator, while the safety valve in the cylinder prevents hydraulic failures.
Parking electromagnetic brake realizes automatic parking functions on slopes for enhanced safety.
Solid tires and a tight turning radius (1793mm) allow for efficient maneuvering in standard warehouse aisles.
Specification
| Parameter | Data |
| Model | CPD20 |
| Rated Capacity (Q) | 2000 kg |
| Load Center (C) | 500 mm |
| Max. Lifting Height (h3) | 3000 mm (Standard) |
| Turning Radius (Wa) | 1793 mm |
| Vehicle Weight | 2900 kg |
| Travel Speed (Full/Unladen) | 9 / 11 km/h |
| Battery | 48V / 300Ah or 350Ah |
