Overview
The KCCL 3 wheel electric forklift is a compact, engineered for exceptional maneuverability in confined spaces. Ideal for high-density warehouses, retail backrooms, and container stuffing/unstuffing, its key advantage is a zero-turn radius dual-drive front axle, allowing it to pivot within its own footprint. Powered by a high-efficiency AC system, the 3 wheel electric forklift delivers precise control, extended runtimes, and low maintenance costs, making it the premier choice for operations looking to maximize productivity in the tightest.
Features
Provides a zero turning radius for unparaileled agility and the ability to operate in extremely narrow aisles.
Designed to navigate congested areas, tight corners, and doorways inaccessible to larger forklifts.
Delivers smooth, responsive acceleration and precise hydraulic control, enhancing operator confidence and load safety.
Recaptures energy during braking and deceleration, feeding it back to the battery to extend shift life.
Its ability to pivot in place allows for narrower aisle configurations, potentially increasing warehouse storage capacity by over 20%.
The dual AC drive motors and regenerative braking result in lower energy consumption per hour, extending battery life and reducing charging costs.
The responsive controller and compact design give operators the finesse needed for delicate loading tasks inside trailers or around machinery.
Fingertip hydraulic controls and a low-effort steering system minimize physical strain during complex, repetitive maneuvers
Specification
| Model | 3 Wheel Forklift |
| Power Type | Electric(AC Drive) |
| Load Capacity | 1200kg-2000kg (3,300lbs-5500lbs) |
| Load Center | 500mm |
| Operator Type | Seated |
| Wheels | 3-Wheel Cushion/Non-Marking(Optional) |
| Mast Type | 2-Stage/3-Stage Full Free Lift(Optional) |
| Max.Lift Height | 3000mm(Standard)to 5500mm(Optional) |
| Travel Speed(L/U) | 7/8 km/h |
| Battery Voltage/Cap | 48V/300Ah (Lead-Acid), 48V/271Ah(Lithium) |
| Turning Radius | 1590mm-1793mm |
| Weight | 1900kg-2900kg(with standard battery) |
